Pulsarlube OL500

Pulsarlube OL500

The Pulsarlube OL500 is our latest innovation in oil lubrication with an average operating pressure of 10bar.

SERIES OL500 : Ø94mm(3.70") x 229mm(9.02") (H)

The Pulsarlube OL500 oil lubricator consists of the main body with a vertical self-priming pump controlled by the microprocessor, a 500ml oil reservoir, and a battery pack. This product has the ability to precisely deliver very small amounts of lubricant with selectable intermittent dispensing cycle. The volume of output is adjustable from 0.70ml to 33.4ml/day, equivalent to the service period of Half month to 24months for the 500ml oil reservoir. It is available with up to 4 feeds by using optional installation kits.

NOTE : The Pulsarlube OL500 is a reusable unit but the battery pack must be replaced when each dispensing period set is complete.

NOTE : The OL500 is also available as MSPOL500/VDC or VAC versions.

Download OL500 User Manual English , MSPOL500 User Manual English and OL500 Flyer English

Image 1 Image 2 Image 3 Image 4 Image 5 Image 6 Image 7
‹
›
Tööstusseadmete eksperdid
Võtke meiega ühendust

Tooted

Features

Item 1
10bar

High operating pressure with a wide range of acceptable oil viscosity

Item 2
Easy to Refill

Easy to refill grease on site using grease nipple
Item 3
Accessory Kit

Up to 4 lube points for multi-point / Max. 6m (20ft) for a single point

Item 4
LCD

Easy to program with built-in LCD and simple button controls

Products info

Cross section

Spec and certifications

Technical Specifications

Spec Description
Oil Reservoir Capacity 500ml (refillable)
Power Supply DC 4.5V Battery Pack
Operating Pressure 10bar (145psi) (depending on oil viscosity)
Operating Temperature Standard Alkaline Battery : -15˚C~60˚C (5˚F~140˚F)
Dispensing Periods 1, 2, 4, 6, 12, 18, 24 month & H (15 days)
Remote Installation Max. 6m (20ft) with O.D. Ø4 tube
Multi-Point Installation Max. 3m (10ft) with O.D. Ø4 tube (Up to 4 lube points)
Oil Viscosity Range 100~10,000 cSt@40˚C * Special instructions available for 10~100 cSt@40˚C
Packaging 10 Units/Case

Product certifications

Certification Description
IP Code IP54

Installation

Single point remote installation Multi-point installation

Kit No. 1250RO-1

reducer
Part No. Description
A002 Reducer, 3/8"F x 1/8"M Adaptor (Brass)
B002 Mounting Bracket, “L”Shape
B057 Washer
A012 Socket, 1/8”F x 1/8”F Adaptor (Brass)
C021-1 O.D. 4mm Nylon Tubing (Clear), 10ft
C010 Tube Clamp, Dia. 4mm x 1R
C007 Tube Fitting, Dia. 4mm x PT1/8"M
C011 Insert, Dia. 4mm x 2.5mm
C009 Sleeve Ring, Dia. 4mm
